B-MAX CAB
B-MAX CAB
Champion of efficiency and versatility
Designed with versatility in mind, the B-Max tractor range is built to cater to a wide variety of applications, including open-field activities, haymaking, vegetable farming, vineyards and orchards. Boasting a fully restyled look, enhanced performance and new functions, the B-Max is now more efficient than ever.
A whole level of reliability and functionality
Engine
4,4 / 4
Power
82 93 102 107 111
Transmission
12F/12R synchro shuttle transmission
The two- and four-wheel drive axles with Hydra-Lock full locking differential manufactured by Argo Tractors provide outstanding traction on all terrains. The four-wheel drive engagement and the electrohydraulic rear differential lock deliver efficiency and safety in any situation.
Our Technology
McCormick enters the era of precision farming, equipping its entire range with an
advanced digital platform that boosts tractor performance and efficiency while significantly
reducing fuel consumption and emissions.
MAIN FEATURES
Available in naturally-aspirated, turbocharged and turbo aftercooled versions, the Perkins 1104D 4.4-litre, 8-valve, 4-cylinder engines deliver from 82 to 111 hp with peak torques from 289 to 416 Nm. A fuel tank with up to 100-litre capacity guarantees long running times without refuelling. The B-Max tractors feature a 12F/12R synchro shuttle transmission and can be equipped with a 16F/16R creeper unit allowing a minimum speed of 0.35 km/h. A 12F/12R power shuttle transmission with de-clutch function is also available for easy forward/reverse shifting and smooth clutchless gear changes. The four-post cab is perfectly sound insulated and ensures excellent all-round visibility and enhanced operator comfort. All versions come equipped with an automotive-style fit and finish, air-suspended driver seat, adjustable steering column, redesigned dashboard, and conveniently-arranged controls.The suspended foot pedals help minimise dust ingress and vibrations. A climate control system and air filters maintain a comfortable work environment all year round. The hydraulic system supplies 54 + 30 l/min to the hydraulic functions and steering system, further enhancing the ride comfort. The B-Max offers up to four rear remote valves and a two-speed PTO with 540/1000 or 540/540E rpm, plus a ground speed PTO. The rear hitch has a maximum lift capacity of 5080 kg.Perkins engines: reliability and durability
Argo Tractors transmissions
Four-post cab
Open-centre hydraulics
x
Perkins engines: reliability and durability
Available in naturally-aspirated, turbocharged and turbo aftercooled versions, the Perkins 1104D 4.4-litre, 8-valve, 4-cylinder engines deliver from 82 to 111 hp with peak torques from 289 to 416 Nm. A fuel tank with up to 100-litre capacity guarantees long running times without refuelling.
x
Argo Tractors transmissions
The B-Max tractors feature a 12F/12R synchro shuttle transmission and can be equipped with a 16F/16R creeper unit allowing a minimum speed of 0.35 km/h. A 12F/12R power shuttle transmission with de-clutch function is also available for easy forward/reverse shifting and smooth clutchless gear changes.
x
Four-post cab
The four-post cab is perfectly sound insulated and ensures excellent all-round visibility and enhanced operator comfort. All versions come equipped with an automotive-style fit and finish, air-suspended driver seat, adjustable steering column, redesigned dashboard, and conveniently-arranged controls.The suspended foot pedals help minimise dust ingress and vibrations. A climate control system and air filters maintain a comfortable work environment all year round.
x
Open-centre hydraulics
The hydraulic system supplies 54 + 30 l/min to the hydraulic functions and steering system, further enhancing the ride comfort. The B-Max offers up to four rear remote valves and a two-speed PTO with 540/1000 or 540/540E rpm, plus a ground speed PTO. The rear hitch has a maximum lift capacity of 5080 kg.
All the accessories and features that make this tractor unique and irreplaceable.
