McCormick X7.6 TIER 3

McCormick X7.6 Tier 3: equipped with the 6.7-litre ‘Betapower Fuel Efficiency’ 24-valve, six-cylinder turbo engines with Common Rail injection system.. There are five models: X7.650, X7.660, X7.670, X7.680 and X7.690 with 166 HP to 225 HP power ratings. It is also equipped with an engine brake pedal to make driving smoother during transport work. It increases braking performance by acting on the exhaust gases. The transmission called P6-Drive is a Powershift type. The P6-Drive transmission includes five robotically-activated ranges and comes with as standard, six Powershift speed gears governed by a dedicated electronic controller. Once the operator has chosen the engine speed, the Smart APS (Smart Autopowershift) system allows the P6-Drive transmission to automatically select the most suitable range and speed gear. Another new feature is the Stop&Action system which integrates the declutch function into the brake pedal, allowing the P6-Drive transmission to provide a smoother ride. Increased to 160 l/min, the flow rate received by the 9,300 kg capacity rear hitch and the control valves, these ones available up to seven. Governed by the Data Screen Manager (DSM) system, the software has also been upgraded and now includes additional functions: a rear view camera to improve visibility over implements hitched behind the tractor and provide more information in the transport mode, advanced headland management functions and additional information from the tractor's onboard computer.

Superior design for maximum comfort and productivity

Engine

6,7/ 6

Power

166, 181, 192, 211, 225

Transmission

Powershift

In addition to the exclusive Premium versions with their highlevel specifications, there are Efficient models which share the same top quality transmissions and engines but come in with entry level features.

Semi-Active Cab Suspension

A new Semi-Active Cab Suspension with electronic controller able to modify shock absorber firmness to suit changing terrain conditions has been introduced to enhance operator comfort to an even greater extent and improve the quality of life and working conditions in the vehicle.

“BETAPOWER” ENGINES: MORE POWER, LESS FUEL

The four models of the McCormick X7.6 series are powered by the new 6.7-liter “Betapower” 24-valve, 6-cylinder turbo engines with Common Rail injection system which provide power ratings from 165 to 225 Hp. The new “Betapower” engines also feature the “Power Plus” system which automatically delivers extra power and torque to cope with demanding PTO and transport work. The tilt-up hood opens wide to provide easy access to the engine compartment for routine service and maintenance. In addition, a special cooling package design allows each of the engine coolers to be separated for easy cleaning.

X7.650 T3 X7.660 T3 X7.670 T3 X7.680 T3 X7.690 T3
TIER 3 BETAPOWER BETAPOWER BETAPOWER BETAPOWER BETAPOWER
MAX. ENGINE POWER WITH POWER PLUS AT 1900 RPM (ISO RATING) hp /kW 166/122 181/133 192/142 211/155  225/166
RATED ENGINE POWER WITH POWER  PLUS AT 2200 RPM (ISO RATING)  HP/KW 151/111  165/121 179/132 192/141  205/151
MAX. TORQUE (WITH POWER PLUS)   MM 632 (676) 694 (738) 758 ( 800) 800 (860)  850 (897)
DISPLACEMENT (CM3) / NO. OF CYLINDERS/ NO. OF VALVES 6728 / 6 / 24 6728 / 6 / 24 6728 / 6 / 24 6728 / 6 / 24  6728 / 6 / 24
FUEL TANK CAPACITY litres 320 320 320 320  320



P6-Drive transmission

The transmission called P6-Drive is a Powershift type. The P6-Drive transmission includes five robotically-activated ranges and comes with as standard, six Powershift speed gears governed by a dedicated electronic controller. Once the operator has chosen the engine speed, the Smart APS (Smart Autopowershift) system allows the P6-Drive transmission to automatically select the most suitable range and speed gear.

Closed-centre hydraulic system

The hydraulic system features a high-flow pump that provides 160 l/min. The electronic management of the hydraulic functions ensures accurate implement control.

DIMENSIONS AND WEIGHTS

X7.650 T3 X7.660 T3 X7.670 T3 X7.680 T3 X7.690 T3
FRONT TYRES 540/65R28 540/65R28 540/65R28 540/65R30 540/65R30
REAR TYRES 650/65R38 650/65R38 650/65R42 650/65R42 650/65R42
D- HEIGHT OVER CAB MM 2920 2920 3055 3055 3055
C- WHEELBASE MM 2750 2750 2820 2820 2820
A- MAX. LENGTH (WITH BALLAST WEIGHTS)    MM 5260 5260 5260 5260 5260
E- GROUND CLEARANCE 4WD MM 485 485 550 550 550
B- MIN. WIDTH  MM 2430 2430 2430 2430 2430
TOTAL WEIGHT WITHOUT BALLAST WEIGHTS KG 7010 7010 7210 7210 7210
