The B-MAX Series
Renewed McCormick B-MAX range, designed for LRC (Low Regulated Countries) markets. The relentless research and development activity has allowed the Italian industrial group based in Fabbrico (Reggio Emilia) to take a significant step forward in the production of tractors that are increasingly at the forefront in terms of innovation, guaranteeing new functions and performance levels, while at the same time improving the design, with European style.
Engine
4,4 / 4
Power
60/68/75/81
Transmission
Gearbox 12FWD + 12REV with synchro shuttle
The standard lifting capacity ranges from 3,000 to 4,500 kilograms (with additional assist cylinders) in the low power versions, while it reaches 5,080 kilograms in the high-power models (110 and 120). The independent PTO has 2 speeds, 540/1000 rpm or 540/540E, with Ground Speed PTO available as an option. The front axles are available in 2-wheel and 4-wheel drive in low power versions (with optional paddy field seals) and only in 4-wheel drive (with optional Hydralock system) for higher powers. The rear differential lock is available with mechanical or electro-hydraulic engagement.
Our Technology
McCormick enters the era of precision farming, equipping its entire range with an advanced digital platform that boosts tractor performance and efficiency while significantly reducing fuel consumption and emissions.
MAIN FEATURES
The transmission provides, as standard, 3 ranges and 4 speeds in each range, resulting in a total 12 forward and 12 reverse speeds for a maximum speed of 30 km per hour. This transmission is available with mechanical reverse shuttle, or the optional Reverse Power Shuttle with modulation control. An optional creep speed option is also available. The hydraulic flow rate to the services (hitch and rear spool valves) is 54 litres/min, while as much as 30 litres/min are available at the steering pump for the version with hydraulic reverse shuttle (24 l/min for mechanical reverse shuttle). An optimised oil filtration system ensures circuit maintenance.
The transmissions allow maximum operability in all working conditions
A WHOLE LEVEL OF RELIABILITY AND FUNCTIONALITY
Read more
Hydraulic circuit
x
The transmissions allow maximum operability in all working conditions
The transmission provides, as standard, 3 ranges and 4 speeds in each range, resulting in a total 12 forward and 12 reverse speeds for a maximum speed of 30 km per hour. This transmission is available with mechanical reverse shuttle, or the optional Reverse Power Shuttle with modulation control. An optional creep speed option is also available.
x
Hydraulic circuit
The hydraulic flow rate to the services (hitch and rear spool valves) is 54 litres/min, while as much as 30 litres/min are available at the steering pump for the version with hydraulic reverse shuttle (24 l/min for mechanical reverse shuttle). An optimised oil filtration system ensures circuit maintenance.
All the accessories and features that make this tractor unique and irreplaceable.
